Mustafa Aluminium, located in Istanbul, Turkey, is a trusted manufacturer and supplier of Aluminium 2017 Channels. Their products are celebrated for their impressive strength, hardness, and durability. Aluminium 2017, a copper-rich alloy from the 2000 series, is well-known for its outstanding mechanical properties, making it a popular choice in the aerospace, automotive, and heavy engineering sectors. Mustafa Aluminium takes pride in crafting 2017 Channels with precision and strict adherence to international standards, ensuring they are perfect for applications that demand reliable, long-lasting, and high-performance aluminium components.
These Aluminium 2017 Channels mainly consist of aluminium, with copper as the primary alloying element, along with trace amounts of magnesium, silicon, and manganese. This unique blend results in high tensile and yield strength, excellent fatigue resistance, and good machinability. The alloy can be heat-treated, which further boosts its mechanical properties for tough applications. While its corrosion resistance is moderate, it can be enhanced through anodizing or protective coatings. Although these channels are not the best for welding, they excel in structural and precision engineering tasks.
Specifications: ASTM B211 / ASME SB211
Temper: O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Thickness: 0.91mm to 10 mm
Length: 10 to 12 Feet or as per clients’ requirement
Width: 9.5 mm X 9.5 mm To 150 mm X 75 mm or Custom
Finish: Mill, Customer specific finish
Surface: Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
Form: C-Channel, Box-Channel, U-Channel, J-Channel, Hat Channel, Strut Channels, Miscellaneous Channels
| Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other Each | Other Total |
| Bal. | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| Al 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
Mustafa Aluminium based in Istanbul, Turkey is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4MgSi | AU4G | 3.1325 | A92017 | AlCu4SiMg | 2017 | AlCuMg1 |
Yes, we offer custom sizes for Aluminium 2017 Channel to meet specific project needs. Our team at Mustafa Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@mustafaaluminium.com
In the aerospace industry, Aluminium 2017 Channels are commonly used for structural parts, aircraft frames, and landing gear, thanks to their remarkable strength and fatigue resistance. In automotive applications, they find their way into gears, chassis, and heavy-duty components. Additionally, they are utilized in defense, machinery, and precision engineering, where hardness, wear resistance, and long-term durability are crucial. With their blend of mechanical strength and reliability, Aluminium 2017 Channels are a top choice for aerospace, automotive, and heavy engineering applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
