Mustafa Aluminium, located in Istanbul, Turkey, is a top manufacturer and supplier of Aluminium 5754 square bars. These bars offer strong quality and precision for demanding uses. Made from wrought Al-Mg alloy 5754, they are produced through extrusion or precision rolling, with careful surface finishing and tight dimensional tolerances. The factory meets relevant international and European standards (EN, ISO) and provides different tempers, such as H111, H22, and H24, to satisfy various strength and formability needs. Known for reliable delivery, full traceability, and strong corrosion resistance, Mustafa Aluminium caters to industries from marine and transport to general fabrication.
Alloy 5754 is a non-heat-treatable aluminium-magnesium alloy in the 5000 series. Its chemical makeup typically includes 2.6-3.6% magnesium, along with small amounts of manganese, chromium, iron, silicon, copper, zinc, and titanium, while aluminium makes up the rest. The mechanical properties vary by temper: in softer forms (like H111), yield strength is about 60-80 MPa with tensile strength around 160-200 MPa and high elongation (greater than 12%). In harder tempers (H22/H24), strengths increase, with tensile strength reaching 240-280 MPa and yield strength around 130-190 MPa, although elongation decreases. The alloy has a density of about 2.66-2.67 g/cm³, a modulus of elasticity of around 68-70 GPa, excellent weldability, and good resistance to fatigue.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 5754 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.40 | 0.40 | 2.60 – 3.60 | 0.50 | 0.10 | 0.20 | 0.15 | Bal |
| Thermal conductivity | Coefficient of thermal expansion | Melting point | Elastic modulus | Electrical conductivity | |||
|---|---|---|---|---|---|---|---|
| Alloy | Temper | W/m*K | µm/(m*K) | Min | Max | KN/mm2 | %IACS |
| EN AW-5754 | Hx2 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx4 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx6 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx8 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| EN AW-5754 | Hx9 | 23,7 | 595 | 645 | 70 | ||
| EN AW-5754 | O | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | DIN | ISO | USA (AA) |
| Aluminium 5754 | A95754 | 3.3535 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 |
Mustafa Aluminium based in Istanbul, Turkey is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 5754 Square Bars to meet specific project needs. Our team at Mustafa Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@mustafaaluminium.com
Our team is ready to assist you. Contact us for any queries or personalized solutions.
