Mustafa Aluminium stands out as a top manufacturer and supplier of Aluminium 7050 Chequered Plates, proudly based in Istanbul, Turkey. Renowned for its precision engineering and dependable performance, the company delivers high-strength aluminium solutions for critical applications around the globe. The Aluminium 7050 Chequered Plates blend the remarkable strength and toughness of the 7050 alloy with a textured, anti-slip surface that boosts safety. Mustafa Aluminium utilizes cutting-edge production techniques to guarantee precise thickness, consistent patterns, and adherence to international quality standards. These plates are trusted across various industries, including aerospace, defense, transportation, and construction, where durability, load-bearing capacity, and corrosion resistance are vital.
Aluminium 7050 Chequered Plates are made from an aluminium alloy that includes zinc (5.7–6.7%), magnesium, copper, and small amounts of chromium. This alloy boasts impressive tensile strength (510–570 MPa) and yield strength (430–505 MPa), along with outstanding toughness and fatigue resistance. Its enhanced resistance to stress-corrosion cracking makes it perfect for heavily loaded structural components. The chequered design not only provides anti-slip features but also maintains structural integrity. The 7050 alloy is heat-treatable, allowing for strength and toughness optimization through tempers like T7451. This blend of mechanical performance and safety features makes these plates ideal for heavy-duty, safety-critical applications.
Standards : ASTM B209 / ASME SB209
Temper : T3, T4, T5, T6, T651 T6511
Thickness : 0.2-300
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| UNS | EN | DIN,WNr | ISO |
| A97050 | EN3982 | 3.4144 | AlZn6CuMgZr |
| Weight % | Zn | Cu | Mg | Zr | Fe | Si | Mn | Ti | Cr | Others (total) |
| Minimum | 5.7 | 2.0 | 1.9 | 0.08 | – | – | – | – | – | – |
| Maximum | 6.7 | 2.6 | 2.6 | 0.15 | 0.15 | 0.12 | 0.10 | 0.06 | 0.04 | 0.15 |
| Material | Temper | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation in 2″ % |
| Aluminium Alloy 7050 Angle (AMS 4340) | T76511 | 79 | 69 | 7 |
| Aluminium Alloy 7050 Angle (AMS 4340) | T73511 | 70 | 60 | 8 |
| Aluminium Alloy 7050 Angle (AMS 4342) | T74511 | 73 | 63 | 7 |
Mustafa Aluminium based in Istanbul, Turkey is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 7050 Chequered Plates to meet specific project needs. Our team at Mustafa Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@mustafaaluminium.com
Aluminium 7050 Chequered Plates find their place in various applications where exceptional strength, durability, and slip resistance are essential. They are perfect for aerospace flooring, walkways, and access platforms, where minimizing weight and maximizing safety are key. In the defense industry, these plates are utilized for vehicle flooring, ramps, and protective covers. Additionally, they are employed in heavy-duty transportation, marine decks, and industrial flooring, where high load capacity and resilience are crucial.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
